Soft Scooter 360
Soft Scooter 360™ is the highly realistic and cost-effective scooter target you
Developed in response to the growing global popularity of scooters, the Soft Scooter 360’s design focuses on enhanced realism, durability, and vehicle protection. The Soft Scooter 360’s realistic shape, speed-matched rotating wheels and photorealistic vinyl skin increases recognition and detection by vehicle sensor systems, including camera, radar and lidar.

It is also compatible with C-NCAP 2021 protocols and meets the ISO/WD 19206-5 standard, making it a vital target for improving the safety of vulnerable powered two wheelers (PTW) riders now, and in the future.
Technical Information
Key to the design of the Soft Scooter 360 has been a focus on reducing the risk of damage to vehicles under test. To achieve this goal, the target’s structure is tubular surrounded by a lightweight foam and hard points have been minimised. The rider is also a separate piece to the scooter, reducing the potential for damage to test vehicles.
Dimensions
Wheelbase 1300mm
Wheel diameter 400mm
Total height 1605mm
Width 641mm
Weight 18kg
Performance
Max operation speed/td> 60km/h
Water resistance Yes
Max frontal/rear impact speed 40km/h
Max side impact speed 60km/h
Compliance
ISO/WD 19206-5 Yes
Radar, camera and lidar Yes
Downloads
Brochure
