LCR-B-S7
Excellent Environmental Resistance Tension Meter Load Cells
Designed for tension meters, LCR-B-S7 series
load cells are suitable for load measurement under
environments where heat resistance, oil resistance,
corrosion resistance and high overload rating are
required.
?? High safe overload rating of 300% max.
?? Mechanical stopper activating against overloads of 150 to 200%
?? Hermetically-sealed structure with inert gas filled in
?? Highly reliable structure (IP64)
?? Corrosion resistant
?? Cable direction selectable from either left or right
Model |
Rated Capacity |
Weight(Approx.)* |
LCR-B-5KNS7 (L, R) |
5kN |
4kg |
LCR-B-10KNS7 (L, R) |
10kN |
LCR-B-20KNS7 (L, R) |
20kN |
LCR-B-30KNS7 (L, R) |
30kN |
4.5kg |
LCR-B-50KNS7 (L, R) |
50kN |
LCR-B-100KNS7 (L, R) |
100kN |
19kg |
LCR-B-200KNS7 (L, R) |
200kN |
Performance |
Rated Capacity |
See table above |
Nonlinearity |
Within??1% RO |
Hysteresis |
Within??1% RO |
Repeatability |
0.3% RO or less |
Rated Output |
1 mV/V (2000??m/m) or more |
Environmental Characteristics |
Safe Temperature Range |
-20 to 100??C |
Compensated Temperature Range |
-10 to 80??C |
Temperature Effect on Zero Balance |
Within ??0.01% RO/??C |
Temperature Effect on Output |
Within ??0.01%/??C |
Electrical Characteristics |
Safe Excitation Voltage |
15V AC or DC |
Recommended Excitation Voltage |
1 to 10V AC or DC |
Input Resistance |
350???1% |
Output Resistance |
350???1% |
Cable |
4-conductor (0.3 mm 2 ) chloroprene shielded cable,
8 mm diameter by 15 m long, bared at the tip |
(Shield wire is not connected to mainframe.) |
Mechanical Properties |
Safe Overload Rating |
150% |
Natural Frequency |
See table above |
Weight |
See table above |
Protection Rating |
IP64 (Splashproof type conforming to JIS C 0920) |
